Specification selection
Product specifications and manuals
Product manual:
Wavelength
532nm
785nm
1064nm
Maximum laser power
Multi mode: 100mW
Single mode: 100mW
Multi mode: 500mW
Multi mode:500mW
Line width
<0.1nm
Range
Typical value:150~3200cm-1
Can provide low wavenumber models
(532: 90cm-1；785: 100cm-1)
Typical value:150~2500cm-1
Resolution ratio
6cm-1
10cm-1
Detector
Back illuminated camera
TE cooled InGaAs camera
Spot size
1um@100x
10um@100x
Multiple options available
10x/20x/50x/100x
Surveying and Mapping Dimensions
50*50mm
Step resolution
200nm
Camera
16 million pixel color CMOS camera
