Product manual：
- Simple structure and small size
- Fast speed and high acceleration
- High thrust and fast response time
- Closed loop control positioning accuracy can reach nanometer level
Specifications and Parameters
Unit
UVCM15-4
UVCM40-5
UVCM110-5
行程/Total Stroke
mm
±2
±2.5
间隙/clearance of side
of Coil
2
3.5
连续推力/Continuous Force
N
15
40
110
峰值推力/Peak Force
35
100
280
推力常数/Force Constant
N/A
7.4
31.2
75.9
反电动势常数/Back EMF
Constant
V/(m/s)
电阻/Electrical Resistance
ohms
3.3
14.80
13.37
电感/Electrical Inductance
mH
2.93
26.80
19.38
时间常数/Electrical Time
ms
0.89
1.81
1.45
连续电流/Continuous Current
A
2.03
1.29
连续功率/Continuous Power
W
13.56
24.64
30.21
峰值电流/Peak Current
4.73
3.23
3.69
峰值功率/Peak Power
76.62
154.01
236.88
电压/Drive Voltage
V
16.2
47.74
64.21
电机常数/Motor Constant
Sqrt(N2/W)
4.07
8.11
13.80
热阻系数/Thermal Resistance
W/℃
4.56
3.2
2.48
最高温度/Max.Coil
Temperature
℃
线圈重量/Meight of
Coil Assembly
g
260
650
912
磁钢重量/Weight of
Field Assembly
520
1404
5580
